Laser SLAM
Handling Autonomous Forklift
FB-2000
The Strongest Forktlift, Flexible and Efficient
Load Type：
FB-2000
2000 kg
Rated load capacity
600 mm
Load center distance
120 mm
Standard lifting height
Open pallet
Pallet type
Precision, punctuality, safety
Laser SLAM Handling Autonomous Forklift
Dramatically reduce costs and improve handling efficiency
High Precision
Pallet recognition + Accurate handling.
Automatic Charging
Support automatic charging without staff.
Flexible Dispatching
Seamless access to dispatching system.
Real Laser SLAM
Easy to deploy with trackless route navigation.
Good Applicability
Ramp, gap, elevator, transfer, stacker.
Parameter Specification
-None ● Standard ○ Optional
| Basic parameters | |
|---|---|
| Product name | Laser SLAM Handling Autonomous Forklift |
| Operation type | Automatic navigation, walk-behind driving |
| Navigation type | Laser SLAM |
| Pallet type | Open pallet |
| Rated load capacity | 2000 kg |
| Load center distance | 600 mm |
| Weight (with battery) | 850 kg |
| Standard lifting height | 120 mm |
| Forklift dimensions: L × W × H | 2075 × 1063 × 2200 mm |
| Fork dimensions: L × W × H | 1150 × 180 × 55 mm |
| Fork outer width | 570 / 680 mm |
| Minimum turning radius | 1850 mm |
| Performance parameters | |
|---|---|
| Driving speed: full load / no load | 1.2 / 1.5 m/s |
| Passability (slope / step / gap) | ＜ 5% / 20 mm / 30 mm |
| Navigation position accuracy | ±10 mm |
| Navigation angle accuracy | ±0.5° |
| Battery parameters | |
|---|---|
| Battery specifications | 24 V / 180 Ah (lithium iron phosphate) |
| Comprehensive Battery life | 10 h |
| Charging time （10% to 80% ） | 2 h |
| Charging method | Manual / Automatic |
| Function configurations | |
|---|---|
| Lidar number | 1 (P+F R2000) + 2 (OLEI LR-1BS2H) |
| Wi-Fi roaming | ● |
| 3D obstacle avoidance | ○ |
| Pallet recognition | ○ |
| HMI display | ● |
| Safety configurations | |
|---|---|
| E-stop button | ● |
| Sound and light indicator | ● |
| Braking distance: 1m/s / 1.5 m/s | ≤30 cm / ≤50 cm |
| Bumper strip | ● |
